Products features

MBP series variable-frequency speed-regulating motor, designed with large scale computer-aided technology, can be matched with the same type of equipment at home and abroad, with strong interchangeability; Motor with axial flow alone since the cooling fan, under different rotational speed of motor has good cooling effect. The motor power, foot installation size and center of higher corresponding indicators are in complete accord with MA series aluminum shell motor. Widely used in light industry, textile, metallurgy, machine tools and so on need speed rotating device applied in the industry, is a kind of ideal speed control power supply.

1. The power of this series is from 0.25-315kw, and the center height of the frame is from h71-355

2. Speed adjustment range: 5-120hz stepless speed adjustment; below 50-60hz, constant torque speed adjustment; Above 50-60hz, the speed is adjusted with constant power.

3. The motor can withstand overload of 160% of the rated torque for 1 minute.

4. At low speed, the torque is smooth and there is no creep

5. The voltage can be raised by the frequency conversion device to ensure that the motor outputs the rated torque at 5HZ without causing the motor to heat up and burn the motor

6. Insulation grades :F and H

7. Protection class: motor IP55,IP56; Axial motor IP54
